MULTI-COIN SHOWER TIMER CONTROLLER WITH PAUSE FUNCTION
This coin-operated controller allows you to manage a shower on a timed basis using euro coins, with the additional convenience of a pause function thanks to the included external button. It is a reliable and widely used solution for campsites, swimming pools, beach resorts, gyms, sports facilities and shared environments.
The user inserts the required amount into the coin controller and the shower is automatically activated for the programmed time, for example €0.50 for 3 minutes.
The unit is supplied complete with accessories, fully programmed, wired and tested, ready for installation and immediate use.
Time and price parameters can be changed at any time by following the supplied instructions. The procedure is simple and intuitive.
Product description
- Structure: powder-coated steel box, RAL 7035 grey, with front door secured by safety key and star key.
- Coin container: internal and removable.
- Multi-coin acceptor: accepts €0.10 – €0.20 – €0.50 – €1 – €2. Token operation available on request.
- LED display: shows inserted credit and remaining shower time.
- Output: 12Vdc with maximum applicable load of 2A.
- Power supply: external 230V / 12Vdc – 2A power adapter included.
- Pause function: temporary stop of shower and timer. External IP55 protected pause button included.
- START function: available for external start button installation near the shower. The START button is not included.
- Change: the unit does not provide change.
- Dimensions: 25 × 16 × 30 cm (W × D × H).
- Installation: wall mounting using expansion anchors.
- Connections: internal terminals for coin controller, solenoid valve and pause button.
- Certification: CE marked, instructions included in Italian.
Installation and warnings
This coin-operated controller can be installed outdoors, but it must be protected from direct exposure to rain and sunlight.
The warranty does not cover damage caused by weather exposure or improper installation.
Installation must be carried out by qualified personnel, in compliance with electrical safety regulations.
TULLIO SERCI S.R.L. declines all responsibility for damage or malfunctions caused by incorrect installation or use not compliant with the appliance manual.
If you require custom parameters, please send us your request using the contact form available below the product page.
